Pharmaceuticals and cosmetics

Features include flow-optimized housings, near-pulsation-free conveyance of media, high dosing accuracy, use of FDA-approved materials, and little dead space for easy cleaning. All in all, WANGEN pumps ensure the highest standards of production for their users.

WANGEN Twin New Generation
Type WANGEN Twin NG

The new generation of the WANGEN Twin NG screw pump is part of the hygienic pumping solutions from WANGEN and was designed to reliably pump low to highly viscous, volatile or gaseous products and for applications where maximum hygiene and efficiency is required.The hygienic pump for food and beverages, chemicals and cosmetics.

  • Spindle replacement without the need to re-synchronise the spindle shafts, thanks to fast-X-change® technology, developed by WANGEN PUMPEN.
  • Cartridge design for simple and quick seal replacement.
  • Coupling alignment by self-centring flange housing (lantern optionally available). Therefore no need for re-alignment of the coupling, for instance after service work



Max. flow rate (m3/h)
200112224336448560
Max. differential pressure (bar)
301632486480
WANGEN MX20S
Type WANGEN MX-S

For demanding hygienic conveying and dosing of aqueous to highly viscous media in the food & beverage-, pharmaceutical and cosmetics industry. Low-impact delivery of products containing solids. CIP and SIP cleaning is possible, the pump is available as a mobile or stationary unit.

Max. flow rate (m3/h)
100112224336448560
Max. differential pressure (bar)
801632486480
WANGEN VarioTwin
Type WANGEN VarioTwin NG

Gently feeding high-viscosity media: The hygienic and patented add-on to the WANGEN Twin screw pump. A add-on module of the WANGEN Twin NG with hopper and screw conveyor.

Max. flow rate (m3/h)
10112224336448560
Max. differential pressure (bar)
251632486480
WANGEN HYLINE Hygienische Exzenterschneckenpumpe Hygienic progressing cavity pump
Type HYLINE

Highlight of the hygienic progressing cavity pump WANGEN HYLINE: The flexible and maintenance-free joint is coated with elastomer. A constant shaft diameter construction design prevents sedimentation of the media to be pumped.

The intelligent design of this hygienic pump requires no additional seals in the product chamber. Pump disassembly is easily carried out by removing all pump component connections outside the product chamber.

Max. flow rate (m3/h)
7112224336448560
Max. differential pressure (bar)
201632486480
Type KB-S

The WANGEN progressing cavity pumps of the KB-S serie are, in contrast to the KL-S serie, equipped with a block housing. There, the drive is coupled directly to the pump housing, which is ideal for normal pump operation or for small conveyed volumes. The pump conveys viscous and abrasive mediums.

Max. flow rate (m3/h)
147112224336448560
Max. differential pressure (bar)
481632486480
KB20S GG
Type KB-S GG

The WANGEN progressing cavity pump KB-S GG is one of the basic products of WANGEN PUMPEN. One of the benefits of this pump is clearly the fewer parts within the individual assemblies. The KB-S GG is of cast iron and has a block housing (the drive is coupled directly to the pump housing).

Max. flow rate (m3/h)
5112224336448560
Max. differential pressure (bar)
161632486480
KL 50 S
Type KL-S

The progressing cavity pump serie WANGEN KL-S are basic products of Pumpenfabrik Wangen. The clear benefit is in the low lifecycle costs. this universally usable pump works with almost every low and extrem high viscous mediums (1 mPas -3.000.000 mPas).

Max. flow rate (m3/h)
560112224336448560
Max. differential pressure (bar)
481632486480
KL 30 SL
Type KL-SL Hygienic

The pumps of the KL-SL serie convince through their easy cleaning and minimal deadspace construction. They can run heat- or coolable. Hygienic highlights are for example CIP (Cleaning in Place) as well as low pulsation and continuous conveying, independent of pressure and viscosity.

Max. flow rate (m3/h)
150112224336448560
Max. differential pressure (bar)
481632486480
Type WANGEN MX-F

The WANGEN MX-F is a hygienic progressing cavity pump for emtying drums and vessels that contains high viscous mediums. The pump is therefore mounted on a plate. Both, pump and plate, is then pressed into the medium. The so displaced material feeds the pump through a hole in the plate.

This ensures the permanent feeding of the pump, even after changing the medium.

Max. flow rate (m3/h)
100112224336448560
Max. differential pressure (bar)
201632486480
