Pumps for Shipbuilding

When pumps are to be used on ships, their design and construction materials must always be viewed with regard to maximum reliability and safety. WANGEN pumps satisfy marine standards and can be issued on request with a DNV certificate. They can be installed in vertical or horizontal position, suffer little wear, and have low failure rates. Wearing parts are easy to replace.

Examples of use:

  • Sludge
  • bilge water (condensate collecting in the keel)
  • oil and fuel residues
  • supplying the oil separator
  • conveying waste water and refuse from the galley and sanitary facilities
Pumpen für Biogas, Pumps for Biogas and anaerobic digestion
Type WANGEN BIO-FEED

With a specially-developed milling screw, you can mix the solids that are to be added with the separately added liquid and convey it into the desired containers.

With our innovative X-LIFT quick-change system, the wearing parts are easy to replace. Only a few simple steps are needed, without this requiring disassembly of the pump from the piping system. Thereby, WANGEN BIO-FEED is also suitable for use in restricted spaces.

Due to the pushing of the screw connection, WANGEN BIO-FEED turns into a high-performance
suction pump. You can use it as a central pump in your biogas plant.

To simplfy integration into your conveyor, our WANGEN BIO-FEED's pump body is equipped with two DN150 connections bearing bracket side, one DN400 connection for the screw conveyor and two DN200 at stator side. In addition, you can use these as cleaning openings and for rinsing the mixing chamber.

Max. flow rate (m3/h)
50132264396528660
Max. differential pressure (bar)
63570105140174
BIO-MIX HD
Type WANGEN BIO-MIX

WANGEN BIO-MIX pumps have been integrated for many years in the energy production process and undergone continuous further development and optimization. They are suitable for conveying maize silage, grass silage, GPS, solid manure, poultry dung, waste and co-ferments, which are mixed with liquid in the pump. Also available with WANGEN PUMPEN's developed and patented X-LIFT quick change system.

Max. flow rate (m3/h)
150132264396528660
Max. differential pressure (bar)
123570105140174
Type KL-R

The WANGEN progressing cavity pump of type KL-R and the specially designed hopper housing and modular sealing system enable the gentle conveyance of mediums without influencing the structure or quality of such. The low dead space version of the KL-RL series is ideal for use in the food industry and particularly easy to clean.

Max. flow rate (m3/h)
160132264396528660
Max. differential pressure (bar)
483570105140174
Type X-UNIT

The modular system for reliable protection of plant equipment:
X-TRACT (debris removal) + X-CUT (substrate cutting) = X-UNIT

The WANGEN X-UNIT consists of the two modules X-TRACT and X-CUT. Both components are available separately and are optimally co-ordinated with each other as an X-UNIT.

Increased process safety through removal of system-harmful foreign bodies and debris with the aid of the foreign body separator X-TRACT and the cutting unit X-CUT. Optimum adaptation of the cutting unit to the medium easily possible.

Max. flow rate (m3/h)
347132264396528660
Max. differential pressure (bar)
63570105140174
KB20S GG
Type KB-S GG

The WANGEN progressing cavity pump KB-S GG is one of the basic products of WANGEN PUMPEN. One of the benefits of this pump is clearly the fewer parts within the individual assemblies. The KB-S GG is of cast iron and has a block housing (the drive is coupled directly to the pump housing).

Max. flow rate (m3/h)
5132264396528660
Max. differential pressure (bar)
163570105140174
KL 50 S
Type KL-S

The progressing cavity pump serie WANGEN KL-S are basic products of Pumpenfabrik Wangen. The clear benefit is in the low lifecycle costs. This universally usable pump works with almost every low and extrem high viscous mediums (1 mPas -3.000.000 mPas).

Max. flow rate (m3/h)
560132264396528660
Max. differential pressure (bar)
483570105140174
WANGEN Xpress
Type WANGEN Xpress

The changing of wear parts with very few actions, without removing the pump from the pipeline system thanks to Service in Place.

The WANGEN Xpress pump range has been specially developed for easy maintenance and to considerably shorten the servicing time and thus reduce costs. Reliable pumping of media, along with fast rotor/stator changes are ensured by the patented X-LIFT quick change system developed by WANGEN PUMPEN. The X-LIFT flange is constructed on standard flange design principles.

Available in the sizes 48, 64, 78 and 94.

Max. flow rate (m3/h)
102132264396528660
Max. differential pressure (bar)
63570105140174
BIO-MIX HD
Type WANGEN BIO-MIX

WANGEN BIO-MIX pumps have been integrated for many years in the energy production process and undergone continuous further development and optimization. They are suitable for conveying maize silage, grass silage, GPS, solid manure, poultry dung, waste and co-ferments, which are mixed with liquid in the pump. Also available with WANGEN PUMPEN's developed and patented X-LIFT quick change system.

Max. flow rate (m3/h)
660132264396528660
Max. differential pressure (bar)
1743570105140174
